Heavy-duty - polyamide

PREMIUM XXL Lenkrolle mit Polyamidrad und Kugellager

Options

Wheel diameter

Load capacity at 4 km/h

Reset configuration

Price excl. tax Price incl. VAT

As low as: €291.55

€245.00

Qty.

Quantity discount

The discount information applies exclusively to our range of wheels and castors

Reference	Parent-vt3v1snsimvmgda4x0zk
Child Products SKUs	1.113.780 / 1.113.781 / 1.113.782 / 1.113.783
Fastening Type	Plate
Running Surface Material	Polyamide
Wheel Material	Polyamide
Maximum temperature resistance	80 °C
Minimum temperature resistance	-30 °C
Country/Region of Origin	IT

Reference	1.113.780
Projection	50 mm
Overall Height	210 mm
Fastening Type	Plate
Running width	100 mm
Hole Spacing	140 x 105
Running Surface Material	Polyamide
Wheel Material	Polyamide
Matches Item Number	1.113.790,1.113.890,1.114.098,1.111.934
Plate width	175 mm
Plate Size in mm	175 x 140
Plate length	140 mm
Wheel width	45 mm
Wheel diameter	125 mm
Screw hole diameter	14 mm
Restricted Goods	No
Maximum temperature resistance	80 °C
Minimum temperature resistance	-30 °C
Load capacity at 4 km/h	1300 kg
Country/Region of Origin	IT
Net weight (kg)	9.35

Reference	1.113.782
Projection	65 mm
Overall Height	285 mm
Fastening Type	Plate
Running width	100 mm
Hole Spacing	160 x 120
Running Surface Material	Polyamide
Wheel Material	Polyamide
Matches Item Number	1.113.792,1.113.892
Plate width	200 mm
Plate Size in mm	200 x 160
Plate length	160 mm
Wheel width	50 mm
Wheel diameter	200 mm
Screw hole diameter	17 mm
Restricted Goods	No
Maximum temperature resistance	80 °C
Minimum temperature resistance	-30 °C
Load capacity at 4 km/h	1800 kg
Country/Region of Origin	IT
Net weight (kg)	12.4

Reference	1.113.781
Projection	50 mm
Overall Height	223 mm
Fastening Type	Plate
Running width	100 mm
Hole Spacing	140 x 105
Running Surface Material	Polyamide
Wheel Material	Polyamide
Matches Item Number	1.113.791,1.113.891,1.111.935
Plate width	175 mm
Plate Size in mm	175 x 140
Plate length	140 mm
Wheel width	45 mm
Wheel diameter	150 mm
Screw hole diameter	14 mm
Restricted Goods	No
Maximum temperature resistance	80 °C
Minimum temperature resistance	-30 °C
Load capacity at 4 km/h	1500 kg
Country/Region of Origin	IT
Net weight (kg)	9.62

Reference	1.113.783
Projection	65 mm
Overall Height	285 mm
Fastening Type	Plate
Running width	100 mm
Hole Spacing	160 x 120
Running Surface Material	Polyamide
Wheel Material	Polyamide
Matches Item Number	1.113.793,1.113.893
Plate width	200 mm
Plate Size in mm	200 x 160
Plate length	160 mm
Wheel width	50 mm
Wheel diameter	200 mm
Screw hole diameter	17 mm
Restricted Goods	No
Maximum temperature resistance	80 °C
Minimum temperature resistance	-30 °C
Load capacity at 4 km/h	2000 kg
Country/Region of Origin	IT
Net weight (kg)	13.64
